Delta Pulse

[szucs_g]

+E, -E are correct value? The first is this. Is 556 working?

[hadi-dindar]

I cant understand you Purpose about +e and _e

i have 10*1.2v=12v buttry

and i have 320hz freq in pin 9 ic 556 without coil.

plz explain about buttry value

tnx

[sparky]

Parts assignment sheet for 7 knob Turkish Delta Pulse?

Originally Posted by sparky
Does anyone have parts placement sheet or schematic for the 7 knob Turkish delta pulse? I found the 6 knob but it's not close enough.

Attachment 21305

[ATTACH]21306[/ATTACH][ATTACH]21307[/ATTACH]

Do you have something like this? It would be much easier to assemble if I had an assignment sheet.

[Nicolas]

Hi Sparky
I join all-round shema for you

do you even create a table
or you are Lazy
Sorry we d'ont have

Best time

Nicolas

[szucs_g]

I cant understand you Purpose about +e and _e

i have 10*1.2v=12v buttry

and i have 320hz freq in pin 9 ic 556 without coil.

plz explain about buttry value

tnx

Very good, how you distribute a frequency the Tr3-on. The two 1N4148 they are properly? Your coil may not be bad. Unless does not close ranks the two cables. This has to work. The two diodes were smoking at me away once, when I fastened a one 2,4 aH battery to the electronics. Why? Don't ask, i don't know.

[supermen]

Hello Japanese
What is the best coil 30cm diameter???

[jap]

Hi supermen
-coil 30 cm 0.5 mm 32 turn =adsl cat5 4x8turn ...4.6 ohm .
best time
j.

[supermen]

Thanks Japanese for the answer, you're always there when we need help,
Greetings

[hadi-dindar]

hi all freinds
so sorry for my question there

i have a cat-5e cable - network cable

when i create a coil 40cm with 3turn cat5 cable and conect the wire i have 15ohm in coil

for example i have 2ohm resistance in reed branch .

plz help me

[jap]

Hi hadi-dindar
The kind that you badly - Use another type.
best time
j.

[hadi-dindar]

Hi hadi-dindar
The kind that you badly - Use another type.
best time
j.

tnx bro
i user cat5-e cable
cat5-e cable 4utp yd/t926.2

[jap]

Hi hadi-dindar
Use another type or Use CAT6(Belden_Cat_6_)
best time
j.

[Nikolov]

Hello my friends

I have Delta pulse with 1x1m square coil, but I want to build round coil with D=32cm what is the best specifications? how many turns, wire diameters, resistance.

Thanks

[jap]

Hi Nikolov
-what is specifications of u 1x1m square coil? the deep?
-coil 32 cm 0.5 mm 32 turn =adsl cat5 or cat 6 4x8turn ...4.6 ohm .
best time
j.

[Nikolov]

1x1m. Wind 17 turns. Use wire with 1mm diameter. If the DC resistance is lower than 2.5 Ohm then connect a resistance in series, so to measure at the connector a dc resistance of 3.5 ohm (3 ... to 4 ohm is ok)

for example coca cola can about 1-1.2m

Thanks JAP
